SPECIFICATION
(SMA-KFD-148)
| Interface According to：IEC 60169-15 | |
Electrical Performance Characteristic Impedance：50 ohm Frequency Range：DC-12GHz VSWR：≤1.15 Dielectric Withstanding Voltage：≥1000V RMS,50Hz,at sea level Dielectric Resistance：≥5000MΩ Contact Resistance：Center Contact ≤3.0mΩ Outer Contact ≤2.5mΩ Durability：Mating cycles ≥500 | Material and plating Body：Brass, Au plating Insulator：PTFE, NATURAL Contact PIN：Brass, Au plating
Environmental Temperature Range：-40℃～+85℃ RoHS：Full RoHS-Compliance |
